    1uF LCD Digital Multimeter

    Ask Lasest Price
    Brand Name : CHX
    Model Number : CHX-DM002
    Certification : CE, RoHS
    Price : Negotiation
    Payment Terms : T/T, Western Union,Paypal,L/C
    Supply Ability : 50000pcs/month
    Delivery Time : 5-35days
    • Product Details
    • Company Profile

    1uF LCD Digital Multimeter

    Description:


    1. True RMS measurement
    2 .NCV measurement
    3. Smart measuring
    4. Diode Test
    5. Continuity Buzzer
    6 .LCD Back light
    7. Low Voltage Display
    8. Data Hold
    9. Flashlight
    10. Auto Power Off


    Maintenance


    1.4.1 Do not attempt to open the bottom case to adjust or repair the instrument. This operation can only be performed by a technician who is fully aware of the instrument and the risk of electric shock.
    1.4.2 Before opening the instrument case or battery cover, remove the test leads from the circuit under test.
    1.4.3 In order to avoid false alarms that may cause errors, when the meter displays the "" symbol,Replace the battery immediately.
    1.4.4 Use a damp cloth and mild detergent to clean the meter, do not use abrasives or solvents.
    1.4.5 When the instrument is not in use, turn off the power and turn the range switch to the OFF position.
    1.4.6 If the instrument is not used for a long time, remove the battery to prevent damage to the instrument.


    Technical indicators

    Ambient temperature: 23 ± 5 ℃ Relative humidity: <75%
    3.2.1 True rms zero input
    3.2.1.1 The measurement of sine wave signal, the use of true RMS measurement method than the traditional average response method error is small.
    3.2.1.2 True RMS The instrument can accurately measure the sine wave signal, but if it is on the AC function, the instrument may display 1 to 50 if the measured signal is not input (shorted at the AC voltage range and the input terminal) Word between a reading. These deviations are normal. Within the specified measuring range, they do not affect the accuracy of the multimeter to measure alternating current.
    3.2.1.3 True RMS requires that the input signal reach a certain level for measurement. Therefore, the AC voltage and current range is specified between 2% and 100% of full scale.


    Specifications:

    Tech Data
    ModelCHX-DM002
    DC Voltage6V/60V/600V
    DC Current1A/10A
    AC Voltage6V/60V/600V
    AC Current1A/10A
    Resistance600Q/6kQ/60kQ/600kQ/6MQ/60MQ
    Capacitance10nF/100nF/1uF/10uF/100uF/1mF/10mF/100mF
    Frequency100Hz/1kHz/10kHz/100kHz/1MHz
    Duty Cycle0.1% - 99%
    Working Temperature0℃ ~ +40℃
    Storage Temperature0℃ ~ +60℃(25℃best)
    Life span>30000hrs
    CertificationCE, RoHS
    Housing Colorcolor
    Item Size16.5*10*5cm
    Item Net Weight208g
    Item Gross Weight340g
    Carton Size57.5*32*33cm / 60pcs/Carton
    Net Weight21Kg
    Gross Weight22Kg
